Sembdner Maschinenbau GmbH

The SEMBDNER HR 60 E Electric Drive manual roller is the further development of the proven SEMBDNER HR60: the integrated, powerful electric motor enables the roller to run smoothly in both forward and reverse gear. Gradients of up to 15% are no longer a problem for the water-filled roller; deep footprints due to heavy pulling in the freshly prepared seedbed are a thing of the past.

For the tennis court, the HR60E is an entry-level version with battery operation as an ideal addition to the large KM1 / KM2 tennis court roller.

The version with lattice roller and mounting bracket for up to 3 GSD trailed seeders is the ideal device in vegetable growing for sowing flower strips and test areas, for weekly sowing or for use in the greenhouse.

Equipment Features:

• sturdy all-steel design
• weight increase with water and minerals
• two resilient, self-adjusting scrapers
• softex handles
• maintenance-free ball bearings
• optionally available with stand or additional weight
• powerful lockable battery including main switch and charge level control
• additional equipment: exchange battery and 12V car charger
• also available as a grid roller
• attachment carrier for GSD available for use with grid roller

more information

SEMBDNER Landscape Seeder RS 50 E Electric Drive

The further development of our landscaper RS 50 H II (purely hand operated up to now) equipped with a wheel hub engine supplied with electricity by a powerful battery

Equipment Features:

• grid front roller and split smooth pressure roller (makes turning round easier)
• detachable weight box
• maintenance-free bearings
• wind-protected seed spout
• powered seed dibbler
• seed rate control
• easy to transport
• powerful battery: up to 1300m2 area performance per charge, even under difficult conditions
• additional equipment: exchange battery and 12V car charger

Upgrade Kit for RS 50 H II available

• Technical data: RS 50 E
• Working width: 50 cm
• Weight approx.: from 63 – 100 kg
• Seed container capacity approx.: 40 litres
• L/W/H approx. (incl. guide spar): 1270 / 590 / 940 mm
• Area performance per charge approx.: 1500 m²

Four operations in one go
SEMBDNER landscape seeders enable perfect lawn sowing using the thousandfold proven sowing principle that was developed by us. In combination with the handy, compact design and the almost legendary durability of our products, this is the reason for the huge success of the SEMBDNER landscape seeders both at home and abroad.

Pre-rolling
The grid front roller crushes larger clods, therefore seed is not sown too deeply and will not be covered by too much soil. At the same time, the grid front roller serves as drive for the brush roller.

Raking the seed into the surface
Thanks to its cleaning cage, the powered seed dibbler also works on stony, cloddy or damp ground and much more evenly than streaking rakes or harrows.

Sowing
The seed sowing device in the seed container has a shaft with flexible, low-wearing Nylon brushes. They are insensitive to small foreign matter and are not prone to jamming as fixed versions would do. The seed-rate determination regulating lever is continuously adjustable.

Rolling the lawn
The pressure roller consolidates soil surface and seeds completely evenly thus causing the seeds to germinate evenly. Pressure roller surface pressure can be changed quickly and precisely depending on soil conditions.
