KUBOTA GIANNI FERRARI S.R.L.

After more than 10 years of study in the Research & Development department, Gianni Ferrari opened the ELECTRIC DEPARTMENT.
The high quality and reliability of an engine-powered lawn mower is combined with the innovation and the green spirit of the new, fully electric models.  Long autonomy, extremely low noise and zero emissions distinguish the GSR+ and GTM+ Electric, the first two models in this new range. The finishes and high performance are those of two great machines.

ELECTRIC EFFICIENCY
GSR+ and GTM+ are professional ride on electric mowers with a Lion battery that combines the highest performance with the extreme manoeuvrability of the existing engine-powered range.
Electric transmission and PTO are the fulcrum of this innovation. Both models have valued features dedicated to the specific needs of a private end-user and a professional user, whether they prefer a front ride on or a mid mount, mulching or collecting.
Two versions for each model, Long and Standard Range, which highlight the need to strive toward an increasingly significant ecological sustainability with zero fuel emissions and considerable reduction in noise, going above all to meet the various economic possibilities of demanding professional and private users .
Respectively with 6 and 8 battery packs by 54V, for Long Range versions, the GTM+ and GSR+ ensure 1000 full charges, working range between -10° and + 60°C and offer a battery life of up to 8 working hours, depending on the grass conditions.

THE ONLY ELECTRIC FRONT RIDE ON MOWER
Agility and compactness of the GSR+ Electric are features that highlight the importance to apply either to a private end-user, but also to the landscaper that adds this unique machine to his fleet.
The finishing of this lawn mower, front 112 cm DUAL CUT deck equipped with three blades and its total installed power of 10.2 kW (equal to 20 Hp of an existing model), ensures a perfect mulching finish and the PTO is completely electric.

• High quality finish due to the grass cutting action before the grass is driven on
• Great adaptability on undulating terrains for a better finish
• Excellent visibility and comfort for the operator

GSR+ Electric goes, with its manoeuvrability, where the mid mounted mowers can’t. GSR+ Electric can be used at a time (early morning / late evening) which until now, contractors or private users by law couldn’t use any type of equipment for green care.
GSR+ Electric also enables REAR DISCHARGE option. The mulching plug placed under the mower deck can simply be removed, thanks to the operation of a conveniently placed lever on the right side (driver’s side) of the mower’s deck.

https://gianniferrari.com/gtmplus-gsrplus-electric/

The ultra-compact GTS represents the middle range excellence of professional lawn mowers offered by Gianni Ferrari, with a powerful engine that is completely hydraulic.
The strengths of this product category include exceptional versatility, remarkable streamlined design and perfect performance on turf surfaces.
Its very small dimensions enhance its extreme flexibility and manoeuvrability even in the narrowest spaces.
Finally, the operating width guarantees usage in 4 different sectors as well as continuous usage throughout the year.

VERSATILITY
The front arrangement of the attachments, both for grass cutting and other works, greatly increases the comfort and operation benefits, enhancing at the same time the high versatility of the GTS, like the entire range of multifunction machines of Gianni Ferrari.
The offer of attachments for the GTS, developed and extended also with the innovative patent of the Smart System that allows to change the blades in the field in less than 15 minutes thanks to brand-new system with magnets, allow the economic investment to be amortized due to the considerable advantage of using the same machine throughout the year.
In fact, the replacement of the attachments is quick and very simple: it requires no tools and only a few seconds thanks to the hydraulic couplings and quick couplings of the hydraulic lift.

DIMENSIONS AND VOLUME
The combination of the front deck or any other attachment, also in front of the power unit as allows the GTS to maintain extremely small dimensions, optimizing the manoeuvrability.
In fact, the GTS offers the ideal combination of versatility and productivity: the proper width of the front attachments allows passage through tight spaces without affecting the hourly productivity.

CUTTING SYSTEM
The cutting decks, as well as any attachment in the range, are located in front of the power unit. In this way, the FRONTAL ACTION allows the user to have maximum visibility and perfect operational control and thus to easily reach spaces not suitable for posterior decks, guaranteeing perfect yield under the bushes and optimized finishing operations around trees, flowerbeds, walls and benches.
Apart from cutting with DIRECT collection, the GTS versatility also offers optimum mulching operations.
The blades of the collection deck are equipped with a blade system that transmits a strong aerodynamic thrust and conveys the grass directly inside the hopper through a wide and low loading channel. The direct grass collection system prevents clogging even in difficult conditions, like high and wet grass.
There are two collection mowing decks that can be selected: the 96 cm version for easy passage through pedestrian access and narrow spaces; the 112 cm version fo increased productivity.
The two-arm hydraulic front linkage allows to easily lift all attachments and easily overcome kerbs and obstacles, thanks to an increased road bump angle of up to 40° and a ground clearance of the power unit of up to 19 cm, thanks to a higher rear wheel.

REDUCED MAINTENANCE
The GTS is a multi-function machine that has been specifically designed to also reduce maintenance and costs.
The direct loading of the grass is certainly a first significant advantage in terms of simplicity of the machine, with a reduction in the number of maintenance operations directly proportional to the lower number of organs subject to wear and replacement, for example: load turbine, impellers and blades.
On the other hand, the hydraulic PTO eliminates the routine maintenance typical of mechanical transmissions, such as tensioning and replacing the belts, greasing the cardan shaft, tensioners and bearings.
The oversized hydraulic components ensure the reliability of the system and maintain the temperature and pressure at low levels, for increased oil life.

https://gianniferrari.com/gts/

Major new developments at the house of Gianni Ferrari: the PG range has been expanded to include the new XPRO model Three exclusive versions, with lots of new technical solutions added, for an impeccable look and extraordinary driving comfort.
Research and development carried out based on the market demand has led Gianni Ferrari to update one of his flagship products, complementing its technical and mechanical efficiency with an innovative design and a bold new look.
The meticulous attention to detail has resulted in a completely new driver’s area. The modern and captivating contours offer more space for the driver, even for getting in and out on both sides.

SAFETY AND INNOVATION
WORKING IS SAFE

Turbine engagement and disengagement independent of the PTO: improved multi-functionality

• USB Port for charging smartphones and electronic devices
• Hydraulic function lock: convenient button on the dashboard for greater road safety
• New ROPS: complete driver protection with the possibility of installing a sun canopy

DRIVING COMFORT
WORKING IS COMFORTABLE

Double pedal for forward and reverse movements

• Parking brake with spring-loaded pedal
• Comfort Seat on the 2WD versions: adjustable armrests, pneumatic suspension*, heating* (*optional)
• Comfort Plus Seat on the 4WD version: ergonomic seat, reclining backrest, adjustable armrests, pneumatic suspension*, heating*
• Next generation steering column: adjustable by depth, LED lights, digital hour-counter display
• Modern dashboard: 2 hydraulic levers with up to 8 functions
• Drink holders in 2 convenient locations
• Advanced Cab design: complete with audio system, heating, large windows, and easy access from both sides

ZERO VIBRATION SYSTEM
WORKING IS PLEASANT

New anti-vibration fastening system for connecting the new platform to the frame: greater driving pleasure

• Innovative spring profile for securing the bulkhead between the turbine and the engine: vibrations reduced to a minimum

ACCESSIBILITY AND MAINTENANCE
WORKING IS EASY

• Innovative unibody platform: greater maintenance accessibility

• Dual side covers: direct interface with the electrical system, hydraulic distributor, and service and transmission oil tanks
• Turbine inlet cover: easier access to the transmission area thanks to the new quick disassembly interface
• Standard auxiliary hydraulic outlets: immediate connection of hydraulic equipment, with easy access under the driving platform
• Battery switch, charging connector, and electrical connection easily accessible beneath the driving platform

https://gianniferrari.com/pg-x-pro/

The latest addition to the Gianni Ferrari range is the Turbo V50. Although it maintains some components and concepts of the classic Turbo 1, 2, 4 range, painstaking attention to detail has resulted in a machine with a completely new engine, PTO and driver area.
Two innovative versions: the first with a redesigned platform to increase user space, the second with a cab to improve comfort even in the harshest of climatic conditions.
An attentive response to market demands in the highest power range and a perfect blend of recent and advanced technologies enhance its new look and rugged style.
Its modern and captivating contours offer more driver space and make getting in and out on both sides easier.

TOTAL INNOVATION
FOR INCREASED SAFETY

Turbine engagement and disengagement independent of the PTO: improved multi-functionality

• USB socket for recharging your smartphone and other devices with the same type of connection
• Side pushbutton panel for full electric operating of the lift and equipment controls when the engine is switched off
• New ROPS: full driver protection, easily foldable for easy transport and storage

INNOVATIVE HEART OF THE MACHINE
THE MOST POWERFUL AND COMPACT IN ITS CATEGORY

Completely new Kubota 50 HP 4-cylinder engine for even more outstanding performance

• Mechanical gear transmission with an oil bath clutch for a longer service life and less maintenance
• Turbine made of wear-resistant steel with a removable, easy to replace rotor

ENHANCED COMFORT AND ZERO VIBRATIONS
FOR UNMATCHED DRIVING PLEASURE

New platform with soft lines which create an even larger driving area

• Grammer comfort seat with adjustable arms, air suspension and heating (optional)
• Innovative height- and rake-adjustable steering column with dashboard with liquid crystal monitor and latest generation software
• Compact, fully reclinable side armrest with optimised control panel
• Practical drink bottle holder
• Spacious glove box (only on models with no cab)
• Complete cabin with amplifier system with 2 speakers and Aux connection, USB socket, heating and air conditioning as standard
• Four new clamping and anti-vibration systems between chassis and platform

ACCESSIBILITY AND MAINTENANCE
MAKING OPERATIONS EASIER

Fully folding platform and cab for easier accessibility and maintenance

• Practical, innovatively designed engine cowling providing access to the whole engine for inspection and replacement
• Standard auxiliary hydraulic outlets: immediate connection of hydraulic equipment with easy access under the driving platform
• Metal side cowling which can be easily removed

https://gianniferrari.com/turbo-v50/

Turboloader is the Gianni Ferrari multi-purpose series with a tool carrier boom and articulated chassis. FUNCTIONAL AND VERSATILE for the most varied professional applications.

Wheel loader, telescopic handler or skid steer loader? Turboloader has it all!

Turboloader has the manoeuvrability of a wheel loader

Turboloader offers the benefits of a telescopic handler

Turboloader has the compact dimensions of a skid steer loader … and it’s even more versatile!

 This is no compromise, it’s a winning combination of great features!

Chassis

The articulated chassis gives a very tight turning radius, reducing the room needed for manoeuvring and enabling Turboloader to move with confidence even in cramped spaces. The articulated chassis and equal sized wheels ensure agile manoeuvring when used indoors or in building yards. Whatever gap the front half-frame goes through, the rear half-frame will follow. The rear wheels always follow the same path of the front ones, minimising compaction of the ground. Its articulated steering means Turboloader can work even on the most delicate surfaces without damage, making it ideal for ideal for landscaping and maintenance of green areas.

Visibility

Unlike a traditional articulated loader, Turboloader’s operator position is located on the machine’s front half-frame. Even when steering the machine, the operator always has a perfect view of the way ahead, the implement and the task being performed. The elevated driving position offers excellent visibility, enhanced safety and superb comfort as well as improving control of the machine and it’s implements. The side-mounted dashboard panel and the layout of the lifting boom rams also assist in providing an uncluttered view of the attachment.

Telescopic boom

Turboloader’s telescopic arm (not available on the MS 220) provides impressive horizontal and vertical reach. The standard hydraulic parallel linkage makes materials handling faster, easier and safer. The self-levelling feature significantly reduces the amount of manual adjustments and loads are lifted in total safety. By selecting the floating arm position, the implements will follow irregular surfaces smoothly and with ease. The simultaneous movement of the arm and bucket helps reduce cycle times and enhance roductivity.

M Range - H Range

The M range of Turboloader is fitted with 3-cylinder 22 - 28 hp engines and, with an operating weight of 1,4

to 2 metric tons, it can handle loads of up to 1.100 kg. H range models have an operating weight from 1,9 to 2,3 metric tons and can handle loads of up to 1.400 kg.

A 4-cylinder 36 hp engine equips the H360 model. The long wheelbase of the H range gives the machine exceptional stability and driving comfort.

This exclusive configuration increases lifting capacity by over 25% compared to the M range, while maintaining the same very compact dimensions and the same manoeuvrability. The optimum weight distribution provides better pushing force delivery and therefore improved bucketing.
