Schäffer tele wheel loaders – an indispensable aid on the building site

Schäffer tele wheel loaders combine the manoeuvrability and clear visibility of an articulated wheel loader with high lift height and range of a conventional telescopic loader. More and more customers are opting for one of the ten models with an operating weight between 2.9 and 13 t.

Due to their articulated steering, Schäffer tele wheel loaders are extraordinarily dynamic in use. The rear end of the vehicle always follows in the tracks of the front end. Manoeuvring is very simple and mobility is great thanks to the high steering angle.

The large, centrally-positioned cab gives the driver perfect all-round visibility. Not least also due to the low front end, whose height has been reduced in comparison with the previous models. This means that the vehicle operator always has a perfect view of the attachments and can work more productively and safely.

Depending on the model, the maximum lifting height is between 3.75 m and 6.10 m. The Ferro-Form sliding members of the telescopic arm are indestructible. The tool cylinder is located within the telescoping arm and thus protected from damage. The machines achieve very good break-out forces through the integrated Z-kinematics, and are therefore the ideal workhorse on the building site. But even in the communal and industrial applications, more and more customers are choosing Schäffer.


More information

The electric wheel loader 24e from Schäffer delivers emission-free operation: exhaust gases and noise are now a thing of the past. This is a significant advantage in emission-sensitive areas such as residential areas, garden facilities and parks, zoos, city centres, cemeteries, the tourism and catering industry, greenhouses and working inside buildings.

The exterior of the machine is similar to the very successful model 2445 S, a 50 hp machine with a bucket capacity of 0.5 m3. In terms of performance, the electric loader is up to the job: even with an extreme low service weight of just 2,450 kg you will still be able to move complete pallets of paving blocks. An additional benefit is that the loader can easily be transported on a car trailer from one building site to another. Even when loading trucks, the machine cuts an impressive figure thanks a lifting height of 2.50 m.

The two charging systems promise flexibility: Schäffer offers an on-board charger as standard, which is operated with a standard 230 V power supply. Add an optional 400 V external charger for even faster charging – the power battery system is charged to 80 % in just 45 minutes. This means enough energy for the entire working day with a quick charge, for example during a lunch break. The battery can be charged at any time without affecting the lifetime – another advantage of lithium-ion technology. Speaking of battery lifetime: Schäffer guarantees a running time of 5,000 charging processes or 5 years of operation, whichever comes first.

www.schaeffer.de/en/24e

Whell loaders by Schäffer: Advantages in the smallest of spaces

All Schäffer loaders lift relatively heavy loads despite low operating weights. The tipping load of the smallest new type 2428-2 machine is already more than 1,000 kg. This is made possible by a specially designed front end. It is lower in comparison with the standard machine, thus improving the driver's view of the tool. The lifting cylinder is stronger.

The thicknesses of the lifting arm was also increased to match the performance gains. The lifting height of the new loaders is between 2.30 m and 3.25 m.

The SLT versions of the machines are also likely to be very interesting. They are characterised by a lower overall height, which is only 1.92 m for the 2428 SLT with an over-head guard. The loaders can thus also drive through very low passages, and are also suitable for use in, e.g., underground car parks. The SLT machines' low centre of gravity results in an even higher tipping load and better stability.
