MSL Mathieu Schalungssysteme und
Lufttechnische Komponenten GmbH

The galvanised composter consists of two U-shaped curved trapezoidal sheeting elements with side lengths of 40 cm and 110 cm.

After the two elements are assembled, the composter can be installed at any desired length between approx. 120 cm and 200 cm. As is the case for the raised bed frame, the sections are connected in the overlapping area. The standard width is 100 cm. The composter can be supplied at heights of 73 cm, 85 cm, and 97 cm. The front side can be closed up with boards on site.

For more information, please click here.


Our stainless steel ovens

All MSL ovens are made exclusively from high quality stainless steel. This means that they can be stored outdoors without difficulty. The oven chamber has a diameter of around 40 cm and is divided into an upper and lower piece. The division is achieved via a pizza plate which is of course authorised for food use. The lower part contains a loose perforated sheet that is placed directly on the burning material. The exhaust pipe with rain cover is simply fixed to the oven pipe using a plug-in system. This enables the oven to be transported easily. The oven is 115 cm high with the exhaust pipe and 67 cm high without the exhaust pipe. A high base with paddle holder is available as an accessory. After setting up the oven the height extends by 79 cm. The total height of the oven in this design is around 194 cm. Before assembling the oven onto the base, we recommend weighing the base down internally using sand or stones to significantly improve the stability. A hinged door and pizza or Flammkuchen paddle can also be supplied.

To bake a Flammkuchen, the fire should be ignited around 20-30 minutes before inserting the Flammkuchen dough. This only requires a little wood. The baking time for a Flammkuchen is 4 to 5 minutes. After around 2 minutes we recommend turning the Flammkuchen through 180° as the temperature is higher in the back part of the oven than at the front. It is not necessary to use a door to bake Flammkuchen.

Attention! The pizza and Flammkuchen oven must always be supervised as soon as the fire has been ignited. When there is a fire inside, the exterior of the oven is extremely hot and there is a risk of burning if the oven is touched. Do not use in closed rooms. Do not place on combustible surfaces. Children must be kept away from the oven. When using the oven, we recommend wearing solid shoes and gloves.

We hope you enjoy your food and love using this high-quality MSL product.

For more information, please click here.

The round plant rings in corrugated profile are available at any diameter from 120 mm. The maximum height is approximately 90 cm. Several corru­gated profile rings of different heights can be combined into a plant pyra­mid, depending on the diameters. This product is also generally available at short notice, even though we produce the plant rings individually for each property. Please ask us.

The square plant elements in trapezoidal profile are in stock in the standard three-part version.

Sizes:
150 cm x 150 cm, 24.5 cm high
100 cm x 100 cm, 49.0 cm high
50 cm x 50 cm, 74.0 cm high

A surrounding edge protector is fitted to the upper edge of the plant elements, which is, however, interrupted at each corner. The square plant elements are also available in other sizes on request.

Our round and square plant pyramids are also available with a round water tank approx. 600 mm in diameter and approx. 385 mm deep.

For more information, please click here.


MSL Raised bed

made from galvanised steel, two-piece

- Standard length 3.00 m, standard width 1.25 m -

The raised bed frame consists of two U-shaped curved trapezoidal sheeting elements with a standard width of approx. 125 cm and a side length of approx. 160 cm. After the two elements are assembled, the raised bed can be installed at any desired length between approx. 165 cm and 300 cm. However, we recommend that the U-shaped elements have a minimum overlap of 12.5 cm.
MSL offers the raised bed in the following heights: 48 cm, 61 cm, 73 cm, 85 cm, and 97 cm.
The delivery contents include a two-piece brace partition, an upper edge protector made from galvanised steel sheeting 50 cm by 125 cm, as well as the necessary self-tapping screws with a screw bit.
As accessories, MSL supplies a cold frame compartment, a five-piece base plate made from expanded metal 1.0 mm thick to protect against rodents, slug protection plates, a slug protection fence and a PVC multi-wall sheet as a top cover for the cold frame and a mount for the multi-wall sheet.

If the raised bed is supplied with a cold frame compartment we recommend attaching our reasonably priced PVC sliding multi-wall sheet to the raised bed with the two guide rails. This version is not nearly as sensitive to wind as a multi-wall sheet that is height-adjustable. The raised bed can be supplied either with a sliding multi-wall sheet or with several sliding multi-wall sheets (see photo).
Caution! The sliding multi-wall sheet is only necessary in the cold season to grow plants from seed. In warmer temperatures the sliding multi-wall sheet can be removed from the raised bed in a matter of seconds. The trapezoidal profile intermediate base is 1.25 m long and 1 m wide. Three base plates and two additional bracing partitions are needed for a standard raised bed.

MSL supplies the following accessories: rodent protection sheet in expanded metal, cold frame compartment, multi-wall sheet with guide rail, slug protection sheets, trapezoidal profile intermediate base and two-part brace partitions for special sizes.

The MSL raised bed is also available in special shapes, e.g. triangular.

For more information, please click here.

All trapezoidal small raised beds are available in two versions. All small raised beds are 1.2 m in length and 0.6 m wide.
The THB and THB plus type terrace and balcony small raised beds are 93 cm high.
Both versions have an opening on the front to enable material to be added, a trapezoidal false floor, an upper circumferential edge protector, and an untreated wood floor with four feed rolls fixed to the floor. All plus versions also have a sliding multi-wall sheet with guide rails to serve as a cover for the frame.

For gardens we offer the following versions:
KHA, KHA plus, KH and KH plus.
Types KHA and KHA plus are approx. 98 cm high and available without a wooden floor or feed rolls. Types KH and KH plus are approx. 98 cm high and are available without a wooden floor, feed rolls or opening on the front.

The following accessories are available for our raised beds:
1) Mounted bed type EH,
approx. 60 x 55 cm in size
2) Storage tray type KU, attachable to all MSL raised beds.

For more information, please click here.
