Model 8.5S K STAGE V

Engine: Kohler KDI 1903 - 3 cylinder 1861 cc -

Emission Standards: Stage V

Power (Iso Gross) / Torque: 57 HP / 225 Nm @ 1500 rpm

Fuel: Diesel

Transmission: Hydrostatic OneDrive

Drive speed (max.): 13 - 26 km/h (8 - 16 mph)

Aux. hydraulics oil flow: 83 l/min (21.9 GPM)

Max. lifting height: 3,2 m (126 in)

Lifting capacity straight, max.: 1640 kg (3615 lbs)

Breakout force / 50 cm: 1700 kg (3748 lbs)

Pushing force (c): 2190 kgf (2190 kp)

Average ground pressure: 890 kg/m2 (182 lbs/sqft)

Turning radius inside/outside: 820/2295 mm (32.2/90.3 in)

Standard tires (Tractor profile): 400/50-15 (31x15.50-15) ET-100

Weight: 1790 kg (3946 lbs)

Features

• Kohler KDI1903TCR, 3 cyl., Turbo common rail diesel engine,
• 1861 cc, water cooled with electric start
• STAGE V
• DPF
• ETC - Electronic Throttle Control
• OneDrive System: DBS (Dynamic Block System), Cruise Control and Torque Divider activated by Joystick
• ACI with Multi-functions joystick (22 functions)
• Unbreakable Body Panels
• Hydraulically pilot operated variable displacement drive pump
• Hi-Flow system
• 2 Speed     Self-locking multi-disk parking brake
• Self-levelling double-H telescopic boom
• Radial Piston high efficiency and heavy duty wheel motors
• 4WD hydrostatic Direct Drive motors, proportional servo control
• Hydraulic oil cooler
• Hydraulic multiconnector
• ROPS-FOPS Level I
• LCD graphic display with programmed service
• 2 front working light
• Ergonomic fully adjustable suspension heated seat with armrests and seat belt
